	COMPLEX LAYOUT The approaches to a major station. LOC: YORK NAME: TRACK-1 I-FCTR: 1.5	TWO TRACK RAILWAY 'Reverse curves' on a two-track railway with one up line and one down line. LOC: CRIGGLESTONE NAME: TRACK-2 I-FCTR: 1.5

	FOUR TRACK RAILWAY A four track railway with two up lines and two down lines. LOC: THIRSK NAME: TRACK-3 I-FCTR: 1.5	SINGLE TRACK RAILWAY A single track railway with movements allowed in both directions. LOC: PENISTONE NAME: TRACK-4 I-FCTR: 2

	TWO TRACK RAILWAY A two-track railway with one up line and one down line. LOC: GREAT HECK NAME: TRACK-5 I-FCTR: 1.5	TWO TRACK RAILWAY A two-track railway with one up line and one down line. LOC: GREAT HECK NAME: TRACK-6 I-FCTR: 1.5

	FOUR TRACK RAILWAY A four track railway with two up lines and two down lines. LOC: THIRSK NAME: TRACK-7 I-FCTR: 1.25	FOUR TRACK RAILWAY A four track railway with two up lines and two down lines. LOC: DIDCOT NAME: TRACK-8 I-FCTR: 1.5

	SINGLE TRACK RAILWAY A single track railway with movements allowed in both directions. LOC: PENISTONE NAME: TRACK-9 I-FCTR: 1.5	SIDINGS LOC: HEALEY MILLS NAME: SIDINGS-1 I-FCTR: 1
